| Rating in Tons | 1200 |
| Die Grip in Tons | 606 |
| HDR SL Stroke | 18" |
| Strokes/Min | 27 |
| Die Opening | 8" |
| Stock Gather | 11" |
| Hold On | 5" |
| Die Height | 36" |
| Die Thickness | 11" |
| Die Seat Length | 26" |
| Tool & Die Space Max | 57" |
| Eccentric Pin Diameter | 16 1/2" |
| Journal Diameter | 14" |
| Flywheel Diameter | 76" |
| Total Energy (ft/Lbs) | 375,090 |
| Clutch Torque (In/Lbs) | 1,411,466 |
| Gear Ratio | 101/17 |
| Torque @ Crankshaft (In/Lbs) | 8,385,762 |
| Motor | 75 HP |
| Floor Space F-B, L-R | 20'-4", 13'-4" |
| Total Machine Height | 12'-4" |
| Depth of Pit | 2'-11" |
| Approximate Weight | 275,000 Lbs. |
